FAP12N Silent model for P4 Prescott LGA775 For Intel P4 Prescott LGA775 3.73GHz

SPECIFICATIONS
Fan( Per Fan )	12025
Operation Voltage	DC 10.2 ~ 13.8 V
Rated Voltage	DC 12V
Input Current	0.16A MAX.
Input Power	1.92W MAX.
Bearing System	NCB
Fan Speed(RPM)	1800±15 %
Max. Air Delivery(CFM)	59.86±15 %
Noise Level	31.73±2 dBA
Fan Safety	UL Approved
Fan with RPM signal output	Yes
Heatsink
Dimension	120 x 120 x 50 mm
Material	Aluminum(6063)
CLIP
Material	Steel(K7)
Thermal Interface	High thermal conductive interface
Material	GW101
Connector	CKM2510 4P(PWM)
Wire Length	200±10 mm
Total Weight	720 g
* NCB = Nano-Ceramic Bearing

APPILATION

For Intel P4 Prescott LGA775 3.73GHz
