P4-Prescott LGA775 Cooler



   FAP12N



Silent model for P4 Prescott LGA775
For Intel P4 Prescott LGA775 3.73GHz

SPECIFICATIONS
Fan( Per Fan ) 12025
Operation Voltage DC 10.2 ~ 13.8 V
Rated Voltage DC 12V
Input Current 0.16A MAX.
Input Power 1.92W MAX.
Bearing System NCB
Fan Speed(RPM) 1800±15 %
Max. Air Delivery(CFM) 59.86±15 %
Noise Level 31.73±2 dBA
Fan Safety UL Approved
Fan with RPM signal output Yes

Heatsink
Dimension 120 x 120 x 50 mm
Material Aluminum(6063)

CLIP
Material Steel(K7)
Thermal Interface High thermal conductive interface
Material GW101
Connector CKM2510 4P(PWM)
Wire Length 200±10 mm
Total Weight 720 g
* NCB = Nano-Ceramic Bearing

APPILATION
For Intel P4 Prescott LGA775 3.73GHz
